Wheel Size
| 28" |
Bike Type
| 19 |
Brake Type
| Disc |
Telescopic Dropper
| No |
Material
| Carbon |
Electric
| no |
Frame
| Oltre XR4 carbon w/Bianchi CV, mechanical/electronic shifting compatible, headset 1.5", PressFit 86,5x41mm BB, Disc brake internal cable routing, flat mount caliper, thru axle 12x142mm, |
Frame Material
| 4 |
Size If you are on a listing page, in this field you will find all the available sizes for that specific product. If you are instead on an ad page, this field reports the Size of the spedific product that is for sale. The Size is one of the most important information for choosing the best fitting product to your body. Wehtere it is a bicycle or gear. Speaking about bike clothing and shoes, sizes follow the international size charts, but when it comes to bicycles and frames it is not possible to define a standard. Bicycles and frames come in many different shapes and geometries and this results in several sizing methods. As a general rule, though, you can assume that road bicycles are sized by the lenght the seat tube in centimeters (52, 54, 56, ...) and mountain bikes are instead sized by the S,M,L, ... rule. Our advice, is to look carefully at the sizing chart you can find in our product pages, but to be sure you are choosing the best fit for you, always refer to your trusted dealer or shop, because he is the one who is the one who can assist you at best for this purpose.
| 47, 50, 53, 55, 57, 59, 61 |
Fork
| Bianchi Full Carbon w/Bianchi CV, 1.5" integrated head, Disc Brake internal cable, flat mount caliper, thru axle 12x100mm |
Suspension Layout
| Rigid |
Headset
| Fsa Orbit custom 5D ACR top cover UD Carbon, lower 1.5"- top 1 .5", 36°- 45° ACB bearing, w/Carbon custom cone spacer specific for Metron DISC integrated handlebar, for 52mm/52mm OD head tube |
Hub Spacing
| Front: 100mm;
Rear: 142mm |
Rims
| Vision 55 SC |
Spokes
| NA |
Inflation Type
| Tubeless |
Tyres
| Pirelli P ZERO™ Race , 26-622, 127TPI, Aramid breaker |
Brakeset
| Included in the shifter |
Shifters
| Sram Red eTap AXS D1 2x12sp |
Front Derailleur
| Sram Red eTap AXS D1 |
Rear Derailleur
| Sram Red eTap AXS D1 12sp |
Crankset
| Sram Red D1 46x33T, Crank Length: 170mm-47/53cm, 172.5mm-55/59cm, 175mm-61cm |
Bottom Bracket
| Sram PressFit Road 86,5x41mm |
Cassette
| Sram Red XG-1290 D1 12sp, 10-11-12-13-14-15-16-17-19-21-24-28T |
Chain
| Sram Red D1 12sp |
Pedals
| Not Included |
Saddle
| Fi'zi:k Argo Vento R1, nylon carbon reinforced shell w/WingFlex, carbon braided 7x10 rail, 260x140mm |
Seatpost
| Reparto Corse Full Carbon Aero special dimension; special Clamp type with alloy head adjustable and reversible +/- 35mm; lenght: 250mm-47cm, 300mm-50/53cm, 350mm-55/59cm, 380-61cm, Setback: 25mm/+10mm |
Stem
| Reparto Corse by Vision Metron 5D ACR Disc Integrated Aero bar, Bar/stem Integrated, material UD Weave Carbon, drop 125mm, reach 80mm, Di2 compatible, RC'21 graphics, Ext: 100x400mm-47/50cm, 110x420mm-53/55cm, 120x420mm-57/59cm, 130x440mm-61cm |
Handlebar
| included in the stem |
Grips
| Black soft Microfiber tapes w/shockproof Eva-139 |
Belongs to MY Catalog
| 2022 |
