Wheel Size
| 29" |
|
Bike Type
| Enduro MTB |
|
Brake Type
| Disc |
|
Telescopic Dropper
| No |
|
Material
| Carbon |
|
Electric
| no |
|
Frame
| Foxy Stealth Air full Carbon, Zero Suspension System, 150mm travel, Forward Geometry, aluminium CSC upper link with carbon bridge, Boost 12x148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, HHG internal cable routing, Enduro MAX sealed bearings, shock mudguard, ISCG 05, custom frame protectors. Optional Geometry Kit, Hanger: Mondraker M068 |
|
Frame Material
| Carbon |
Size  If you are on a listing page, in this field you will find all the available sizes for that specific product. If you are instead on an ad page, this field reports the Size of the spedific product that is for sale. The Size is one of the most important information for choosing the best fitting product to your body. Wehtere it is a bicycle or gear. Speaking about bike clothing and shoes, sizes follow the international size charts, but when it comes to bicycles and frames it is not possible to define a standard. Bicycles and frames come in many different shapes and geometries and this results in several sizing methods. As a general rule, though, you can assume that road bicycles are sized by the lenght the seat tube in centimeters (52, 54, 56, ...) and mountain bikes are instead sized by the S,M,L, ... rule. Our advice, is to look carefully at the sizing chart you can find in our product pages, but to be sure you are choosing the best fit for you, always refer to your trusted dealer or shop, because he is the one who is the one who can assist you at best for this purpose. | S, M, L, XL |
|
Size Notes
| S: 380mm / M: 420mm / L: 470mm / XL: 510mm |
|
Front Suspension
| Fox 36 29 Float FIT4 EVOL Factory Kashima, 160mm, tapered steerer tube, 15x110mm axle, offset 44mm. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload |
|
Front Suspension Travel
| 160 |
|
Shock
| Fox Float DPX2 LV EVOL Factory Kashima, 205x62.5mm. Settings: compression 3 positions lever, low-speed compression, low-speed rebound, air preload. Trunnion top mount, 22.2x10mm bottom bushings; Shock Settings: Light compression, extralight rebound, air volume spacer 0.6 |
|
Rear Suspension Travel
| 205 |
|
Suspension Layout
| Full Suspended |
|
Headset
| Onoff Titan tapered for 1-1/8†to 1-1/2†head tube, ACB sealed bearings, top 41.8x30.5x8x45°x45°, bottom 51.9x40x8x45°x45° |
|
Front Hub
| DT 350, 15x110mm, CL |
|
Rear Hub
| DT 350, 12X148mm, CL, MicroSpline freehub |
|
Hub Spacing
| Front: 110mm Boost;
Rear: 148mm Boost |
|
Rims
| DT Swiss E1700 Spline 29, 30mm internal width, tubeless ready, 28 spokes |
|
Spokes
| DT Competition, straight pull |
|
Inflation Type
| Tubeless |
|
Tyres
| Front: Maxxis Minion DHR II 29x2.4 WT, Tubeless ready, 3C Maxx Terra compound, EXO protection, 60TPI, folding bead; Rear: Maxxis Aggressor 29x2.3, Tubeless ready, dual compound, EXO protection, 60TPI, folding bead |
|
Brakeset
| Front: Shimano Deore XT M8120, 4-piston caliper, MT800 203mm CenterLock rotor, resin pads; Rear: Shimano Deore XT M8120, 4-piston caliper, MT800 180mm CenterLock rotor, resin pads; Lever: Shimano XT, ergonomic antiskid lever with servo wave, tool less reach adjust |
|
Shifters
| Shimano XT SL-M8100, Rapid Fire Plus, 12s |
|
Rear Derailleur
| Shimano XT RD-M8100, SGS, Shadow Plus, 12s |
|
Crankset
| Shimano XT M-8120 Boost, Hollowtech 2, MT800 axle, S/M size: 170mm, L/XL size: 175mm; Rings: 32T, CNC-machined alloy |
|
Bottom Bracket
| Shimano Deore XT BB-MT800 BSA |
|
Cassette
| Shimano XT CS-M8100 10-51T Hyperglide+, 12s |
|
Chain
| Shimano Deore XT M8100, 12s |
|
Pedals
| Not Included |
|
Power Meter
| No |
|
Saddle
| SDG Fly MTN, PU foam, Cr-Mo rails, Cordura sides |
|
Seatpost
| Onoff Pija dropper internal, diameter 31.6mm, S size: 337x100mm, M size 387x125mm, L/XL size: 425x150mm |
|
Stem
| Onoff Krypton FG 30mm, 6061 forged alloy, 35mm barbore |
|
Handlebar
| Onoff Krypton Carbon 0.5, rise: 12,5mm, width: 780mm, 9° backsweep, 5° upsweep, 35mm barbore |
|
Grips
| Onoff Desert, 1lock-on, 135mm sizes: S/M L/XL |
|
Belongs to MY Catalog
| 2020 |
