Wheel Size
| 29" |
|
Bike Type
| eMTB |
|
Brake Type
| Disc |
|
Telescopic Dropper
| No |
|
Material
| Carbon |
|
Electric
| yes |
|
Frame
| Crafty Stealth Air full Carbon, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers. Derailleur hanger : Mondraker M068 |
|
Frame Material
| Carbon |
Size  If you are on a listing page, in this field you will find all the available sizes for that specific product. If you are instead on an ad page, this field reports the Size of the spedific product that is for sale. The Size is one of the most important information for choosing the best fitting product to your body. Wehtere it is a bicycle or gear. Speaking about bike clothing and shoes, sizes follow the international size charts, but when it comes to bicycles and frames it is not possible to define a standard. Bicycles and frames come in many different shapes and geometries and this results in several sizing methods. As a general rule, though, you can assume that road bicycles are sized by the lenght the seat tube in centimeters (52, 54, 56, ...) and mountain bikes are instead sized by the S,M,L, ... rule. Our advice, is to look carefully at the sizing chart you can find in our product pages, but to be sure you are choosing the best fit for you, always refer to your trusted dealer or shop, because he is the one who is the one who can assist you at best for this purpose. | S, M, L, XL |
|
Size Notes
| S: 380mm, M: 420mm, L: 450mm, XL: 490mm |
|
Front Suspension
| Öhlins RXF 38 M.2 29, 170mm, TTX18 Twin Tube cartridge, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload, ramp chamber |
|
Front Suspension Travel
| 170 |
|
Shock
| Öhlins TTX Air 205X65mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload. Trunnion top mount, 25x10mm bottom bushings |
|
Rear Suspension Travel
| 205 |
|
Suspension Layout
| Full Suspended |
|
Headset
| Acros custom for 1-1/2" head tube, angular contact bearings 40x52x7, Internal cable routing |
|
Front Hub
| Mavic, Boost 15x110mm, IS 6 bolts |
|
Rear Hub
| Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, XD freehub |
|
Hub Spacing
| Front: 110mm Boost;
Rear: 148mm Boost |
|
Rims
| Mavic E-Deemax S 29, 30mm internal width, Maxtal welded, PFP, tubeless, 28 spokes |
|
Spokes
| Mavic straightpull duble butted, contactless lacing |
|
Inflation Type
| Tubeless |
|
Tyres
| Front: Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead, Rear: Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead |
|
Brakeset
| SRAM Code RSC, oversized 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads, Lever: SRAM Code RSC, SwingLink and lever pivot bearings, tools-free reach and contact point adjust |
|
Shifters
| SRAM Trigger GX Eagle, 12s, X-Actuation 1:1, single click |
|
Rear Derailleur
| SRAM X01 Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1 |
|
Crankset
| E.13 TRS Race carbon ebike, 165mm |
|
Cassette
| SRAM XG-1275, 10-52T, 12s |
|
Chain
| SRAM NX Eagle, 12s, Powerlock |
|
Pedals
| Not Included |
|
Power Meter
| No |
|
Saddle
| FIZIK Terra Aidon X5 145mm |
|
Seatpost
| ONOFF Pija dropper internal, diameter 31.6mm, S size: 387x125mm, M size: 425x150mm, L/XL size: 465x170mm |
|
Stem
| ONOFF Krypton FG 30mm, CNC, 31.8mm barbore |
|
Handlebar
| ONOFF Krypton Carbon 1.0, rise: 25mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore |
|
Grips
| ONOFF Diamond, 1lock-on, 135mm |
|
Motor Brand
| Bosch |
|
Motor Model
| Performance Line CX - Derailleur (MY 22) |
|
Battery Brand
| Bosch |
|
Battery Model
| PowerTube 750 |
|
Belongs to MY Catalog
| 2022 |
