Wheel Size
| 29" |
|
Bike Type
| eMTB |
|
Brake Type
| Disc |
|
Telescopic Dropper
| No |
|
Material
| Aluminium |
|
Electric
| yes |
|
Frame
| Chaser 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers, shock mudguard. DerailleurHanger: Mondraker M068 |
|
Frame Material
| Aluminium |
Size  If you are on a listing page, in this field you will find all the available sizes for that specific product. If you are instead on an ad page, this field reports the Size of the spedific product that is for sale. The Size is one of the most important information for choosing the best fitting product to your body. Wehtere it is a bicycle or gear. Speaking about bike clothing and shoes, sizes follow the international size charts, but when it comes to bicycles and frames it is not possible to define a standard. Bicycles and frames come in many different shapes and geometries and this results in several sizing methods. As a general rule, though, you can assume that road bicycles are sized by the lenght the seat tube in centimeters (52, 54, 56, ...) and mountain bikes are instead sized by the S,M,L, ... rule. Our advice, is to look carefully at the sizing chart you can find in our product pages, but to be sure you are choosing the best fit for you, always refer to your trusted dealer or shop, because he is the one who is the one who can assist you at best for this purpose. | S, M, L, XL |
|
Size Notes
| S: 380mm, M: 420mm , L: 450mm, XL: 490mm |
|
Front Suspension
| Fox 36 29 Float FIT GRIP EVOL Rythm, 160mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, 44mm offset. Settings: sweep adjust compression, Low-speed rebound, air preload |
|
Front Suspension Travel
| 160 |
|
Shock
| RockShox Deluxe Select R Debonair, 205x65mm. Settings: Low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings |
|
Rear Suspension Travel
| 205 |
|
Suspension Layout
| Full Suspended |
|
Headset
| ONOFF Saturn tapered for 1-1/8†to 1-1/2†head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º |
|
Front Hub
| Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolts |
|
Rear Hub
| Formula EHL148 Boost 12x148mm, sealed bearings, IS 6 bolts |
|
Hub Spacing
| Front: 110mm Boost;
Rear: 148mm Boost |
|
Rims
| MDK-HP1 29, 30mm internal width, tubeless ready, 32 spokes |
|
Spokes
| CN round stainless steel |
|
Inflation Type
| Tubeless |
|
Tyres
| Maxxis Rekon 29x2.6, tubeless ready, dual compound, EXO protection, 60TPI, folding bead |
|
Brakeset
| SRAM G2 R, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads, Lever: SRAM G2 R, tool-free reach adjust |
|
Shifters
| SRAM Trigger SX Eagle, 12s, X-Actuation 1:1, single click |
|
Rear Derailleur
| SRAM SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1 |
|
Crankset
| Race Face Aeffect ebike, 165mm, Rings: SRAM X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD |
|
Cassette
| SRAM PG-1210, 11-50T, 12s |
|
Chain
| SRAM SX Eagle, 12s, Powerlock |
|
Pedals
| Not Included |
|
Power Meter
| No |
|
Saddle
| FIZIK Terra Aidon X5 145mm |
|
Seatpost
| ONOFFPija dropper internal, diameter 31.6mm, S size: 387x125mm, M size: 425x150mm, L/XL size: 465x170mm |
|
Stem
| ONOFF Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore |
|
Handlebar
| ONOFFSulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore |
|
Grips
| ONOFF Diamond, 1lock-on, 135mm |
|
Motor Brand
| Bosch |
|
Motor Model
| Performance Line CX - Derailleur (MY 22) |
|
Battery Brand
| Bosch |
|
Battery Model
| PowerTube 750 |
|
Belongs to MY Catalog
| 2022 |
