Merida Big.Nine 20-3x Bike - 2022

€790.00
Add to My Wishlist Brand's Product Page Brand's Website
Listing
Notify me for this product
This product is a Listing product. If you are interested in this product, please let us know! Just click here above, leave your email and we will notify you as soon as a Vendor will put on sale this product!

Specs Overview

Brand Merida
Product Type Bike
Category Bikes | MTB | Cross Country
Model Year 2022
Model Big.Nine 20-3x
Color Matt fall green (black), white (purple), teal blue (lime),matt dark silver (silver)
Select Configuration
Loading...

Description

Triple chainring equipped entry-level 29er aluminium hardtail featuring a more upright and, therefore, more comfortable riding position than our more race-focused hardtails. The riding position puts less strain on the lower back and also improves the visibility of what lies ahead. A 100 mm suspension fork from SR Suntour and hydraulic disc brakes improve comfort and control even further. Mountain biking is one of the most varied cycling disciplines and probably the most demanding when it comes to equipment. While full suspension bikes offer amazing riding characteristics, the classic hardtail remains one of the purest tools for the job. Our 29er wheel equipped BIG.NINE range comes in carbon and aluminium and features multiple geometry options. The carbon and LITE framed BIG.NINE, with its racing geometry, is an ideal companion on XC and marathon race tracks whilst the more relaxed geometry of the BIG.NINE TFS and SPEED offers a more comfortable, upright riding position. Our classic hardtails are the backbone of our range and showcase the enormous wealth of experience and knowledge we could gain in almost half a century of bike production and manufacturing. The BIG.NINE range symbolises the symbiosis between modern frame technology, attention to detail and craftsmanship 'Made in Taiwan'.
Read More... Hide

Wheel Size
29"
Bike Type
Cross Country MTB
Brake Type
Disc
Telescopic Dropper
No
Material
Aluminium
Electric
no
Frame
Big.Nine TFS III material: aluminum 29x2.25" max. wheelsize 135x9mm axle standard BSA bottom bracket standard
Frame Material
Aluminium
Size

If you are on a listing page, in this field you will find all the available sizes for that specific product. If you are instead on an ad page, this field reports the Size of the spedific product that is for sale.

The Size is one of the most important information for choosing the best fitting product to your body. Wehtere it is a bicycle or gear. Speaking about bike clothing and shoes, sizes follow the international size charts, but when it comes to bicycles and frames it is not possible to define a standard. Bicycles and frames come in many different shapes and geometries and this results in several sizing methods. As a general rule, though, you can assume that road bicycles are sized by the lenght the seat tube in centimeters (52, 54, 56, ...) and mountain bikes are instead sized by the S,M,L, ... rule. Our advice, is to look carefully at the sizing chart you can find in our product pages, but to be sure you are choosing the best fit for you, always refer to your trusted dealer or shop, because he is the one who is the one who can assist you at best for this purpose.

S, M, L, XL, XXL
Front Suspension
Suntour XCT30 HLO Coil 100mm suspension travel lockout 29x2.25" max. wheelsize
Front Suspension Travel
100
Suspension Layout
Front Suspended
Headset
Merida M2345
Hubs
Shimano TX505
Front Hub
100x9mm width front hub 32 spoke holes Centerlock
Rear Hub
135x9mm width rear hub 32 spoke holes Centerlock
Hub Spacing
Front: 100mm; Rear: 135mm
Rims
Merida CC 17mm inner width material: aluminium
Spokes
Black steel
Inflation Type
Inner Tube
Tyres
Merida K1080 29x2.2" wire
Brakeset
Shimano ST-EF505 BR-MT200 brake caliper rotors Shimano RT10 160 mm
Shifters
Shimano ST-EF505
Front Derailleur
Shimano FD-TY700
Rear Derailleur
Shimano RD-M360
Crankset
Shimano TY301 42-34-24 teeth 170 mm-S, 175 mm-M/XXL
Bottom Bracket
FSA TH-7420ST-W, Cartridge Bearing
Cassette
Sunrace CSM668 11-32 teeth 8 speed
Chain
Sunrace M84
Pedals
VP VPE-891
Power Meter
No
Saddle
Merida Sport comfort
Seatpost
Merida CC material: aluminium 30.9mm diameter 15mm setback
Stem
Merida CC material: aluminium 31.8mm diameter 6° stem angle 70 mm-S, 80 mm-M, 90 mm-L, 100 mm-XL, 110 mm-XXL
Handlebar
Merida CC material: aluminium 690mm width 15mm rise
Grips
Merida EC
Belongs to MY Catalog
2022

Weight Limit
135 kg
Women Specific
no
Kid Specific
no
Integrated Lights
No
Integrated Lock
No

Eureka SKU

The Eureka SKU is a universal product code (UPC) that univocally defines a specific product in the bicycles' market.

Sharing the Eureka SKU of a listing bicycle, for example, means to indicate a very well-defined combination of Brand, Model, Mounting, and Model Year parameters that define a single bike model and no one else. The Eureka SKU of an Ad product, instead, is built from other information that guarantees it is still unique compared to all present, past, and future products managed by EurekaBike.

2111150118
Manufacturer Code

The Manufacturer Code is a unique code that defines a particular Model from the side of the producer or brand. Often, this code can be found in manufacturers' catalogs or websites, but due to producers not adopting always the same standards, when the Manufacturer Code is not available, at EurekaBike we give the product an internally created Manufacturer Code based on the defining parameters of the product itself.

Big-Nine-20-3x
RRP (EUR)RRP Means Recommended Retail Price. It is to say, the price that the manufacturer suggest to shop for selling a certain item. It is usually the maximum price you can find for a specific item, sold as new.
€790.00
Weight (gr)
NA
