Wheel Size
| 28" |
|
Bike Type
| Performance Road Bike |
|
Brake Type
| Disc |
|
Telescopic Dropper
| No |
|
Material
| Carbon |
|
Electric
| no |
|
Frame
| Ultralight 800 Series OCLV Carbon, Ride Tuned performance tube optimization, tapered head tube, internal routing, DuoTrap S compatible, flat mount disc, 142x12mm thru axle
Max tire size: 30c |
|
Frame Material
| Carbon |
Size  If you are on a listing page, in this field you will find all the available sizes for that specific product. If you are instead on an ad page, this field reports the Size of the spedific product that is for sale. The Size is one of the most important information for choosing the best fitting product to your body. Wehtere it is a bicycle or gear. Speaking about bike clothing and shoes, sizes follow the international size charts, but when it comes to bicycles and frames it is not possible to define a standard. Bicycles and frames come in many different shapes and geometries and this results in several sizing methods. As a general rule, though, you can assume that road bicycles are sized by the lenght the seat tube in centimeters (52, 54, 56, ...) and mountain bikes are instead sized by the S,M,L, ... rule. Our advice, is to look carefully at the sizing chart you can find in our product pages, but to be sure you are choosing the best fit for you, always refer to your trusted dealer or shop, because he is the one who is the one who can assist you at best for this purpose. | 47,50,52,54,56,58,60,62 |
|
Fork
| Emonda SLR full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm thru axle |
|
Suspension Layout
| Rigid |
|
Headset
| NA |
|
Rear Hub
| Bontrager Aeolus, OCLV Carbon, Tubeless Ready, Shimano 11/12 speed freehub, 142x12mm thru axle
w/Skewer rear: Bontrager Switch thru axle, removable lever |
|
Hub Spacing
| Front: 100mm;
Rear: 142mm |
|
Rims
| Bontrager Aeolus RSL 37, OCLV Carbon, Tubeless Ready, 37mm rim depth, 100x12mm thru axle
w/Rim strip: Bontrager Aeolus XXX |
|
Spokes
| NA |
|
Front Wheel
| Bontrager Aeolus RSL 37, OCLV Carbon, Tubeless Ready, 37mm rim depth, 100x12mm thru axle
w/Skewer front: Bontrager Switch thru axle, removable lever |
|
Rear Wheel
| Bontrager Aeolus RSL 37, OCLV Carbon, Tubeless Ready, 37mm rim depth, 142x12mm thru axle |
|
Inflation Type
| Tubeless |
|
Tyres
| Size: 47, 50, 52, 54, 56, 58, 60, 62
Bontrager R4 320 Handmade Clincher, Hard-Case Lite, 320 tpi, 700x25c
Size: 47, 50, 52, 54, 56, 58, 60, 62
Bontrager R3 Hard-Case Lite, aramid bead, 120 tpi, 700x25c |
|
Brakeset
| SRAM Red eTap AXS hydraulic disc, flat mount
Brake rotor SRAM CenterLine X, centerlock, round edge, 160mm |
|
Shifters
| SRAM RED eTap AXS, 12 speed |
|
Front Derailleur
| SRAM RED eTap AXS, braze-on |
|
Rear Derailleur
| Size: 47, 50, 52, 54, 56, 58, 60, 62
SRAM RED eTap AXS, Orbit chain management, 33T max cog
Size: 47, 50, 52, 54, 56, 58, 60, 62
SRAM RED eTap AXS, 36T max cog |
|
Crankset
| Size: 47
SRAM RED AXS Power Meter, 48/35, DUB spindle, 165mm length
Size: 50, 52
SRAM RED AXS Power Meter, 48/35, DUB, 170mm length
Size: 54, 56, 58
SRAM RED AXS Power Meter, 48/35, DUB, 172.5mm length
Size: 60, 62
SRAM RED AXS Power Meter, 48/35, DUB, 175mm length
Max chainring size 1x: 50T, 2x: 53/39T |
|
Bottom Bracket
| SRAM DUB, T47 threaded, internal bearing |
|
Cassette
| SRAM XG-1290, 10-33, 12 speed |
|
Chain
| SRAM RED D1, 12 speed |
|
Pedals
| Not included |
|
Power Meter
| No |
|
Saddle
| Size: 47, 50, 52, 54, 56, 58, 60, 62
Bontrager Aeolus Pro, carbon rails, 145mm width
Size: 47, 50, 52
Bontrager Aeolus P2 Pro, carbon rails, 155mm width |
|
Seatpost
| Size: 47, 50, 52, 54
Bontrager carbon seatmast cap, 20mm offset, short length
Size: 56, 58, 60, 62
Bontrager carbon seatmast cap, 20mm offset, tall length |
|
Stem
| Size: 47, 50
Bontrager Aeolus RSL Integrated bar/stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 38cm width, 80mm stem length
Size: 52
Bontrager Aeolus RSL Integrated bar/stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 40cm width, 90mm stem length
Size: 54
Bontrager Aeolus RSL Integrated bar/stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 42cm width, 90mm stem length
Size: 56
Bontrager Aeolus RSL Integrated bar/stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 42cm width, 100mm stem length
Size: 58
Bontrager Aeolus RSL Integrated bar/stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 42cm width, 110mm stem length
Size: 60, 62
Bontrager Aeolus RSL Integrated bar/stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 44cm width, 110mm stem length |
|
Handlebar
| Size: 47, 50
Bontrager Aeolus RSL Integrated bar/stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 38cm width, 80mm stem length
Size: 52
Bontrager Aeolus RSL Integrated bar/stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 40cm width, 90mm stem length
Size: 54
Bontrager Aeolus RSL Integrated bar/stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 42cm width, 90mm stem length
Size: 56
Bontrager Aeolus RSL Integrated bar/stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 42cm width, 100mm stem length
Size: 58
Bontrager Aeolus RSL Integrated bar/stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 42cm width, 110mm stem length
Size: 60, 62
Bontrager Aeolus RSL Integrated bar/stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 44cm width, 110mm stem length |
|
Grips
| Bontrager Supertack Perf tape |
|
Belongs to MY Catalog
| 2022 |
