Wheel Size
| 28" |
|
Bike Type
| Performance Road Bike |
|
Brake Type
| Disc |
|
Telescopic Dropper
| No |
|
Material
| Carbon |
|
Electric
| no |
|
Frame
| Ultralight 500 Series OCLV Carbon, Ride Tuned performance tube optimization, tapered head tube, internal routing, DuoTrap S compatible, flat mount disc, 142x12mm thru axle
Max tire size: 30c |
|
Frame Material
| Carbon |
Size  If you are on a listing page, in this field you will find all the available sizes for that specific product. If you are instead on an ad page, this field reports the Size of the spedific product that is for sale. The Size is one of the most important information for choosing the best fitting product to your body. Wehtere it is a bicycle or gear. Speaking about bike clothing and shoes, sizes follow the international size charts, but when it comes to bicycles and frames it is not possible to define a standard. Bicycles and frames come in many different shapes and geometries and this results in several sizing methods. As a general rule, though, you can assume that road bicycles are sized by the lenght the seat tube in centimeters (52, 54, 56, ...) and mountain bikes are instead sized by the S,M,L, ... rule. Our advice, is to look carefully at the sizing chart you can find in our product pages, but to be sure you are choosing the best fit for you, always refer to your trusted dealer or shop, because he is the one who is the one who can assist you at best for this purpose. | 47,50,52,54,56,58,60,62 |
|
Suspension Layout
| Rigid |
|
Headset
| NA |
|
Hub Spacing
| Front: 100mm;
Rear: 142mm |
|
Front Wheel
| Bontrager Aeolus Elite 35, OCLV Carbon, Tubeless Ready, 35mm rim depth, 100x12mm thru axle
w/Skewer front: Bontrager Switch thru axle, removable lever |
|
Rear Wheel
| Bontrager Aeolus Elite 35, OCLV Carbon, Tubeless Ready, 35mm rim depth, Shimano 11/12-speed freehub, 142x12mm thru axle
w/Skewer rear: Bontrager Switch thru axle, removable lever |
|
Inflation Type
| Tubeless |
|
Tyres
| Bontrager R2 Hard-Case Lite, aramid bead, 60 tpi, 700x25c |
|
Brakeset
| Shimano Ultegra hydraulic disc, flat mount
Brake rotor Shimano RT800, centerlock, 160mm |
|
Shifters
| Size: 47, 50, 52
Shimano Ultegra R8025, short-reach lever, 11 speed
Size: 54, 56, 58, 60, 62
Shimano Ultegra R8020, 11-speed |
|
Front Derailleur
| Shimano Ultegra R8000, braze-on |
|
Rear Derailleur
| Shimano Ultegra R8000, short cage, 30T max cog |
|
Crankset
| Size: 47
Shimano Ultegra R8000, 52/36, 165mm length
Size: 50, 52
Shimano Ultegra R8000, 52/36, 170mm length
Size: 54, 56, 58
Shimano Ultegra R8000, 52/36, 172.5mm length
Size: 60, 62
Shimano Ultegra R8000, 52/36, 175mm length
Max chainring size 1x: 50T, 2x: 53/39T |
|
Bottom Bracket
| Praxis, T47 threaded, internal bearing |
|
Cassette
| Shimano Ultegra R8000, 11-30, 11 speed |
|
Chain
| Shimano Ultegra HG701, 11-speed |
|
Pedals
| Not included |
|
Power Meter
| No |
|
Saddle
| Bontrager Aeolus Comp, steel rails, 145mm width |
|
Seatpost
| Size: 47, 50, 52, 54
Bontrager carbon seatmast cap, 20mm offset, short length
Size: 56, 58, 60, 62
Bontrager carbon seatmast cap, 20mm offset, tall length |
|
Stem
| Size: 47
Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 70mm length
Size: 50
Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 80mm length
Size: 52, 54
Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 90mm length
Size: 56
Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 100mm length
Size: 58, 60, 62
Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 110mm length |
|
Handlebar
| Size: 47, 50
Bontrager Elite VR-C, alloy, 31.8mm, 100mm reach, 124mm drop, 38cm width
Size: 52
Bontrager Elite VR-C, alloy, 31.8mm, 100mm reach, 124mm drop, 40cm width
Size: 54, 56, 58
Bontrager Elite VR-C, alloy, 31.8mm, 100mm reach, 124mm drop, 42cm width
Size: 60, 62
Bontrager Elite VR-C, alloy, 31.8mm, 100mm reach, 124mm drop, 44cm width |
|
Grips
| Bontrager Supertack Perf tape |
|
Belongs to MY Catalog
| 2022 |
