Wheel Size
| 28" |
|
Bike Type
| Performance Road Bike |
|
Brake Type
| Disc |
|
Telescopic Dropper
| No |
|
Material
| Carbon |
|
Electric
| no |
|
Frame
| 500 Series OCLV Carbon, front & rear IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, DuoTrap S compatible, fender mounts, flat mount disc, 142x12mm thru axle
Max tire size: 38c |
|
Frame Material
| Carbon |
Size  If you are on a listing page, in this field you will find all the available sizes for that specific product. If you are instead on an ad page, this field reports the Size of the spedific product that is for sale. The Size is one of the most important information for choosing the best fitting product to your body. Wehtere it is a bicycle or gear. Speaking about bike clothing and shoes, sizes follow the international size charts, but when it comes to bicycles and frames it is not possible to define a standard. Bicycles and frames come in many different shapes and geometries and this results in several sizing methods. As a general rule, though, you can assume that road bicycles are sized by the lenght the seat tube in centimeters (52, 54, 56, ...) and mountain bikes are instead sized by the S,M,L, ... rule. Our advice, is to look carefully at the sizing chart you can find in our product pages, but to be sure you are choosing the best fit for you, always refer to your trusted dealer or shop, because he is the one who is the one who can assist you at best for this purpose. | 44,47,50,52,54,56,58,60,62 |
|
Fork
| Domane SL carbon, tapered carbon steerer, internal brake routing, fender mounts, flat mount disc, 12x100mm thru axle |
|
Suspension Layout
| Rigid |
|
Headset
| NA |
|
Hub Spacing
| Front: 100mm;
Rear: 142mm |
|
Rims
| Bontrager Paradigm Comp 25, Tubeless Ready, 25mm rim width, 100x12mm thru axle
w/Rim strip: Bontrager TLR |
|
Spokes
| NA |
|
Front Wheel
| Bontrager Paradigm Comp 25, Tubeless Ready, 25mm rim width, 100x12mm thru axle
w/Skewer front: Bontrager Switch thru axle, removable lever |
|
Rear Wheel
| Bontrager Paradigm Comp 25, Tubeless Ready, 25mm rim width, SRAM XD-R 12-speed freehub, 142x12 thru axle
w/Skewer rear: Bontrager Switch thru axle, removable lever |
|
Inflation Type
| Tubeless |
|
Tyres
| Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 120 tpi, 700x32c |
|
Tubes
| Bontrager TLR sealant, 6oz |
|
Brakeset
| Brake rotor SRAM Paceline, rounded, centerlock, 160mm |
|
Shifters
| SRAM Rival eTap AXS, 12 speed |
|
Front Derailleur
| SRAM Rival eTap AXS, braze-on |
|
Rear Derailleur
| SRAM Rival eTap AXS |
|
Crankset
| Size: 47
SRAM Rival, 46/33, DUB, 165mm length
Size: 50, 52
SRAM Rival, 46/33, DUB, 170mm length
Size: 54, 56
SRAM Rival, 46/33, DUB, 172.5mm length
Size: 58, 60, 62
SRAM Rival, 46/33, DUB, 175mm length |
|
Bottom Bracket
| SRAM DUB, T47 threaded, internal bearing |
|
Cassette
| SRAM XG-1250, 10-36, 12 speed |
|
Chain
| SRAM Rival, 12 speed |
|
Pedals
| Not included |
|
Power Meter
| No |
|
Saddle
| Size: 47, 50, 52
Bontrager P3 Verse Comp, steel rails, 155mm width
Size: 54, 56, 58, 60, 62
Bontrager P3 Verse Comp, steel rails, 145mm width |
|
Seatpost
| Size: 47, 50, 52, 54, 56
Bontrager carbon internal seatmast cap, integrated light mount, 20mm offset, short length
Size: 58, 60, 62
Bontrager carbon internal seatmast cap, integrated light mount, 20mm offset, tall length |
|
Stem
| Size: 47
Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 70mm length
Size: 50
Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 80mm length
Size: 52, 54
Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 90mm length
Size: 56, 58
Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 100mm length
Size: 60, 62
Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 110mm length |
|
Handlebar
| Size: 47
Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 36cm width
Size: 50
Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 38cm width
Size: 52
Bontrager Elite IsoZone VR-SF, alloy, 31.8mm, internal Di2 routing, 75mm reach, 128mm drop, 40cm width
Size: 54, 56
Bontrager Elite IsoZone VR-CF, alloy, 31.8mm, internal Di2 routing, 93mm reach, 123mm drop, 42cm width
Size: 58, 60, 62
Bontrager Elite IsoZone VR-CF, alloy, 31.8mm, internal Di2 routing, 93mm reach, 123mm drop, 44cm width |
|
Grips
| Bontrager Supertack Perf tape |
|
Belongs to MY Catalog
| 2022 |
