Wheel Size
| 29" |
|
Bike Type
| Enduro MTB |
|
Brake Type
| Disc |
|
Telescopic Dropper
| No |
|
Material
| Aluminium |
|
Electric
| no |
|
Frame
| 2022 Meta TR, 140mm travel - 29'', Alloy 6066, triple butted tubes, T4, T6. Enduro bearings |
|
Frame Material
| Aluminium |
Size  If you are on a listing page, in this field you will find all the available sizes for that specific product. If you are instead on an ad page, this field reports the Size of the spedific product that is for sale. The Size is one of the most important information for choosing the best fitting product to your body. Wehtere it is a bicycle or gear. Speaking about bike clothing and shoes, sizes follow the international size charts, but when it comes to bicycles and frames it is not possible to define a standard. Bicycles and frames come in many different shapes and geometries and this results in several sizing methods. As a general rule, though, you can assume that road bicycles are sized by the lenght the seat tube in centimeters (52, 54, 56, ...) and mountain bikes are instead sized by the S,M,L, ... rule. Our advice, is to look carefully at the sizing chart you can find in our product pages, but to be sure you are choosing the best fit for you, always refer to your trusted dealer or shop, because he is the one who is the one who can assist you at best for this purpose.
| S, M, L, XL |
|
Front Suspension
| OHLINS RXF36 m.2 Air, 150mm travel - 29", TTX 18 damper, Ramp Up chamber, LSC, HSC, rebound, Boost (15x110mm), 44mm offset |
|
Front Suspension Travel
| 150 |
|
Shock
| OHLINS TTX1 Air - 210x55mm, climb mode, Adjustable HSC (High-Speed Compression), LSC (Low-Speed Compression) and Rebound damping |
|
Rear Suspension Travel
| 140 |
|
Suspension Layout
| Full Suspended |
|
Headset
| ACROS ZS44/ZS56 - Alloy cups, sealed bearings |
|
Front Hub
| DT SWISS 350 - 28h, sealed bearings, 15x110mm, black |
|
Rear Hub
| DT SWISS 350 - 28h, sealed bearings, 12x148mm, Micro Spline, 36t ratchet, black |
|
Hub Spacing
| Front: 110mm Boost;
Rear: NA |
|
Rims
| F: DT SWISS XM 1700 29'' - 29'', 28h, 30mm inner width, R: DT SWISS XM 1700 29'' - 29'', 28h, 30mm inner width |
|
Spokes
| DT SWISS Competition - Straightpull, 2.0-1.8-2.0mm, double butted, stainless, with Nylok, black |
|
Tyres
| F: SCHWALBE Nobby Nic - 29"x2.35", Super Trail, Addix Soft, Tubeless Ready; R:SCHWALBE Magic Mary - 29"x2.4", Super Trail, Addix Soft, Tubeless Easy |
|
Brakeset
| SHIMANO XT - 4 pistons, I-Spec EV compatible w/ SHIMANO SM-RT86 203mm - 6-bolt, Ice Technology Freeza rotors |
|
Shifters
| SHIMANO XT - 12s |
|
Rear Derailleur
| SHIMANO XT - 12s |
|
Crankset
| SHIMANO XT - 170mm crank arms, Boost w/ SHIMANO XT - 32t, Dynamic Chain Engagement + Technology chainring |
|
Bottom Bracket
| SHIMANO BBMT800 - Pressfit |
|
Cassette
| SHIMANO XT - 12s, 10-51t |
|
Chain
| SHIMANO XT - 12s |
|
Pedals
| Not Included |
|
Power Meter
| No |
|
Saddle
| SDG Bel Air V3 Atmos - Lux-Alloy Rails |
|
Seatpost
| KS Lev Integra - 34.9mm, travel: 125mm on S, 150mm on M, 175mm on L, 200mm on XL, SouthPaw alloy remote |
|
Stem
| RIDE ALPHA Freeride 40 - 40mm extension, 31.8mm |
|
Handlebar
| RIDE ALPHA R20 760 on S
RIDE ALPHA R27 780 on M / L
RIDE ALPHA R27 800 on XL - 31.8mm, 760mm width, 20mm rise, Alloy 6061 on S
31.8mm, 780mm width, 27mm rise, Alloy 6061 on M / L
31.8mm, 800mm width, 27mm rise, Alloy 6061 on XL |
|
Grips
| ODI Elite Motion - Soft pro compound, single clamp, black |
|
Belongs to MY Catalog
| 2022 |
