Wheel Size
| 27.5" & 29" |
|
Bike Type
| Cross Country MTB |
|
Brake Type
| Disc |
|
Telescopic Dropper
| No |
|
Material
| Aluminium |
|
Electric
| no |
|
Frame
| Alpha Gold Aluminum, tapered head tube, internal derailleur & dropper post routing, rack & kickstand mount, Boost141, 5mm QR
Max tire size: 27.5x2.80" |
|
Frame Material
| Aluminium |
Size  If you are on a listing page, in this field you will find all the available sizes for that specific product. If you are instead on an ad page, this field reports the Size of the spedific product that is for sale. The Size is one of the most important information for choosing the best fitting product to your body. Wehtere it is a bicycle or gear. Speaking about bike clothing and shoes, sizes follow the international size charts, but when it comes to bicycles and frames it is not possible to define a standard. Bicycles and frames come in many different shapes and geometries and this results in several sizing methods. As a general rule, though, you can assume that road bicycles are sized by the lenght the seat tube in centimeters (52, 54, 56, ...) and mountain bikes are instead sized by the S,M,L, ... rule. Our advice, is to look carefully at the sizing chart you can find in our product pages, but to be sure you are choosing the best fit for you, always refer to your trusted dealer or shop, because he is the one who is the one who can assist you at best for this purpose. | XS,S,M,M/L,L,XL,2XL |
|
Front Suspension
| Size: XS
RockShox Judy SL, Solo Air spring, TurnKey lockout, tapered steerer, 42mm offset, Boost110, 15mm Maxle Lite, 80mm travel
Size: S
RockShox Judy SL, Solo Air spring, TurnKey lockout, tapered steerer, Boost110, 15mm Maxle Lite, 100mm travel
Size: M, M/L, L, XL, XXL
RockShox Judy SL, Solo Air spring, TurnKey lockout, tapered steerer, Boost110, 15mm Maxle Stealth, 100mm travel |
|
Front Suspension Travel
| 100 |
|
Suspension Layout
| Front Suspended |
|
Headset
| Semi-integrated, loose ball bearing, 1-1/8'' top, 1.5'' bottom |
|
Front Hub
| Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15mm thru axle |
|
Rear Hub
| Bontrager alloy, sealed bearing, 6-bolt, Shimano MicroSpline freehub, Boost141, 5mm QR |
|
Hub Spacing
| Front: 100mm;
Rear: 141.5mm |
|
Rims
| Size: XS, S, M, M/L, L, XL, XXL
Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23mm width, presta valve
Size: XS, S, M, M/L, L, XL, XXL
Bontrager Kovee, double-wall, Tubeless Ready, 32-hole, 23mm width, presta valve
w/rimstrip: Bontrager TLR |
|
Spokes
| 14g stainless steel |
|
Inflation Type
| Tubeless |
|
Tyres
| Size: XS, S
Maxxis Ardent Race, tubeless, EXO casing, folding bead, 60tpi, 27.5x2.35''
Size: M, M/L, L, XL, XXL
Maxxis Ardent Race, tubeless, EXO casing, folding bead, 60tpi, 29x2.35'' |
|
Tubes
| Bontrager TLR sealant, 6oz |
|
Brakeset
| Shimano MT200 hydraulic disc
*Brake rotor Size: XS, S, M, M/L, L, XL, XXL
Shimano RT26, 6-bolt,160mm
Size: L, XL, XXL
Shimano RT26, 6-bolt,180mm |
|
Shifters
| Shimano Deore M6100, 12 speed |
|
Rear Derailleur
| Shimano XT M8100, long cage |
|
Crankset
| Size: XS, S, M
Shimano MT511, 30T steel ring, 52mm chainline, 170mm length
Size: M/L, L, XL, XXL
Shimano MT511, 30T steel ring, 52mm chainline, 175mm length
Max chainring size 32T |
|
Bottom Bracket
| Shimano SM-BB52, 73mm, threaded external bearing |
|
Cassette
| Shimano Deore M6100, 10-51, 12 speed |
|
Chain
| Shimano Deore M6100, 12 speed |
|
Pedals
| VP-536 nylon platform |
|
Power Meter
| No |
|
Saddle
| Bontrager Arvada, steel rails, 138mm width |
|
Seatpost
| Size: XS, S
Bontrager alloy, 31.6mm, 12mm offset, 330mm length
Size: M
Bontrager alloy, 31.6mm, 12mm offset, 360mm length
Size: M/L, L, XL, XXL
Bontrager alloy, 31.6mm, 12mm offset, 400mm length |
|
Stem
| Size: XS, S
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 60mm length
Size: M, M/L
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 70mm length
Size: L
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length
Size: XL, XXL
Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 90mm length |
|
Handlebar
| Size: XS
Bontrager alloy, 31.8mm, 5mm rise, 690mm width
Size: S, M
Bontrager alloy, 31.8mm, 5mm rise, 720mm width
Size: M/L, L, XL, XXL
Bontrager alloy, 31.8mm, 15mm rise, 750mm width |
|
Grips
| Bontrager XR Trail Comp, nylon lock-on |
|
Belongs to MY Catalog
| 2022 |
