Wheel Size
| 29" |
|
Bike Type
| Cross Country MTB |
|
Brake Type
| Disc |
|
Telescopic Dropper
| No |
|
Material
| Carbon |
|
Electric
| no |
|
Frame
| OCLV Mountain Carbon, IsoSpeed, tapered head tube, Knock Block, internal control routing, balanced post mount brake, Boost148
Max tire size: 29x2.40" |
|
Frame Material
| Carbon |
Size  If you are on a listing page, in this field you will find all the available sizes for that specific product. If you are instead on an ad page, this field reports the Size of the spedific product that is for sale. The Size is one of the most important information for choosing the best fitting product to your body. Wehtere it is a bicycle or gear. Speaking about bike clothing and shoes, sizes follow the international size charts, but when it comes to bicycles and frames it is not possible to define a standard. Bicycles and frames come in many different shapes and geometries and this results in several sizing methods. As a general rule, though, you can assume that road bicycles are sized by the lenght the seat tube in centimeters (52, 54, 56, ...) and mountain bikes are instead sized by the S,M,L, ... rule. Our advice, is to look carefully at the sizing chart you can find in our product pages, but to be sure you are choosing the best fit for you, always refer to your trusted dealer or shop, because he is the one who is the one who can assist you at best for this purpose. | S,M,M/L,L,XL,2XL |
|
Front Suspension
| RockShox Recon Gold RL, DebonAir spring, Motion Control damper, remote lockout, tapered steerer, 42mm offset, Boost110, 15mm Maxle Stealth, 100mm travel |
|
Front Suspension Travel
| 110 |
|
Suspension Layout
| Front Suspended |
|
Headset
| Knock Block Integrated, 62-degree radius, cartridge bearing, 1-1/8'' top, 1.5'' bottom |
|
Hub Spacing
| Front: 110mm Boost;
Rear: 148mm Boost |
|
Rims
| Bontrager Kovee Comp 23, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle
w/rimstrip: Bontrager TLR |
|
Spokes
| NA |
|
Front Wheel
| Bontrager Kovee Comp 23, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle |
|
Rear Wheel
| Bontrager Kovee Comp 23, Tubeless Ready, Shimano Microspline freehub, Rapid Drive 108, Boost148
w/Skewer rear: Bontrager Switch thru axle, removable lever |
|
Inflation Type
| Tubeless |
|
Tyres
| Bontrager XR2 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29x2.20'' |
|
Tubes
| Bontrager TLR sealant, 6oz |
|
Brakeset
| Shimano hydraulic disc, MT4100 lever, MT410 caliper
*Brake rotor Size: S , M , ML , L , XL , XXL
Shimano RT56, 6-bolt, 180mm
Size: S , M , ML , L , XL , XXL
Shimano RT56, 6-bolt, 160mm |
|
Shifters
| Shimano SLX M7100, 12 speed |
|
Rear Derailleur
| Shimano XT M8100, long cage |
|
Crankset
| Size: S
Shimano MT611, 30T steel ring, alloy spider, 52mm chainline, 170mm length
Size: M , ML , L , XL , XXL
Shimano MT611, 30T steel ring, alloy spider, 52mm chainline, 175mm length
Max chainring size 36T, Min 30T |
|
Bottom Bracket
| Shimano MT500, 92mm, PressFit |
|
Cassette
| Shimano SLX M7100, 10-51, 12 speed |
|
Chain
| Shimano Deore M6100, 12 speed |
|
Pedals
| Not included |
|
Power Meter
| No |
|
Saddle
| Bontrager Arvada, hollow chromoly rails, 138mm width |
|
Seatpost
| Size: S
Bontrager Comp, 6061 alloy, 31.6mm, 8mm offset, 330mm length
Size: M , ML , L , XL , XXL
Bontrager Comp, 6061 alloy, 31.6mm, 8mm offset, 400mm length |
|
Stem
| Size: S , M
Bontrager Rhythm Comp, 31.8mm, Knock Block, 0 degree, 60mm length
Size: ML
Bontrager Rhythm Comp, 31.8mm, Knock Block, 0 degree, 70mm length
Size: L , XL
Bontrager Rhythm Comp, 31.8mm, Knock Block, 0 degree, 80mm length
Size: XXL
Bontrager Elite, 35mm, 0 degree, 90mm length |
|
Handlebar
| Size: S , M , ML
Bontrager Comp, alloy, 31.8mm, 5mm rise, 720mm width
Size: L , XL
Bontrager Rhythm Comp, alloy, 31.8mm, 15mm rise, 750mm width
Size: XXL
Bontrager Line, alloy, 35mm, 15mm rise, 750mm width |
|
Grips
| Herrmans Clik |
|
Belongs to MY Catalog
| 2022 |
