Wheel Size
| 29" |
|
Bike Type
| Cross Country MTB |
|
Brake Type
| Disc |
|
Telescopic Dropper
| No |
|
Material
| Carbon |
|
Electric
| no |
|
Frame
| OCLV Mountain Carbon, IsoSpeed, tapered head tube, Knock Block, internal control routing, balanced post mount brake, Boost148
Max tire size: 29x2.40" |
|
Frame Material
| Carbon |
Size  If you are on a listing page, in this field you will find all the available sizes for that specific product. If you are instead on an ad page, this field reports the Size of the spedific product that is for sale. The Size is one of the most important information for choosing the best fitting product to your body. Wehtere it is a bicycle or gear. Speaking about bike clothing and shoes, sizes follow the international size charts, but when it comes to bicycles and frames it is not possible to define a standard. Bicycles and frames come in many different shapes and geometries and this results in several sizing methods. As a general rule, though, you can assume that road bicycles are sized by the lenght the seat tube in centimeters (52, 54, 56, ...) and mountain bikes are instead sized by the S,M,L, ... rule. Our advice, is to look carefully at the sizing chart you can find in our product pages, but to be sure you are choosing the best fit for you, always refer to your trusted dealer or shop, because he is the one who is the one who can assist you at best for this purpose. | S,M,M/L,L,XL,2XL |
|
Front Suspension
| RockShox Judy SL, Solo Air spring, TurnKey lockout, tapered steerer, Boost110, 15mm Maxle Stealth, 100mm travel |
|
Front Suspension Travel
| 110 |
|
Suspension Layout
| Front Suspended |
|
Headset
| Knock Block Integrated, 62-degree radius, cartridge bearing, 1-1/8'' top, 1.5'' bottom |
|
Front Hub
| Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15mm thru axle |
|
Rear Hub
| Bontrager alloy, sealed bearing, 6-bolt, Shimano MicroSpline freehub, Boost148, 12mm thru axle |
|
Hub Spacing
| Front: 110mm Boost;
Rear: 148mm Boost |
|
Rims
| Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23mm width, presta valve
w/rimstrip: Bontrager TLR |
|
Spokes
| NA |
|
Front Wheel
| Bontrager Kovee TLR rim/DC-611 Boost hub, 29'', 28H, 15 Gauge Spokes, Black/Black |
|
Rear Wheel
| Bontrager Kovee TLR rim/MST148A Boost hub, 29'', 28H, 15 Gauge Spokes, Micro Spline Freehub, Black rim graphics, spokes, and nipples
w/Skewer rear: Bontrager Switch thru axle, removable lever |
|
Inflation Type
| Tubeless |
|
Tyres
| Bontrager XR2 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29x2.20'' |
|
Tubes
| Bontrager TLR sealant, 6oz |
|
Brakeset
| Shimano MT200 hydraulic disc
*Brake rotor Size: S, M, M/L, L, XL
Shimano RT26, 6-bolt,160mm
Size: L, XL
Shimano RT26, 6-bolt,180mm |
|
Shifters
| Shimano Deore M6100, 12 speed |
|
Rear Derailleur
| Shimano Deore M6100, long cage |
|
Crankset
| Size: S, M
Shimano MT511, 30T steel ring, 52mm chainline, 170mm length
Size: M/L, L, XL
Shimano MT511, 30T steel ring, 52mm chainline, 175mm length
Max chainring size 36T, Min 30T |
|
Bottom Bracket
| Shimano MT500, 92mm, PressFit |
|
Cassette
| Shimano Deore M6100, 10-51, 12 speed |
|
Chain
| Shimano Deore M6100, 12 speed |
|
Pedals
| Not included |
|
Power Meter
| No |
|
Saddle
| Bontrager Arvada, steel rails, 138mm width |
|
Seatpost
| Size: S
Bontrager alloy, 31.6mm, 12mm offset, 330mm length
Size: M
Bontrager alloy, 31.6mm, 12mm offset, 360mm length
Size: M/L, L, XL
Bontrager alloy, 31.6mm, 12mm offset, 400mm length |
|
Stem
| Size: S
Bontrager Rhythm Comp, 31.8mm, Knock Block, 0 degree, 60mm length
Size: M, M/L
Bontrager Rhythm Comp, 31.8mm, Knock Block, 0 degree, 70mm length
Size: L, XL
Bontrager Rhythm Comp, 31.8mm, Knock Block, 0 degree, 80mm length |
|
Handlebar
| Size: S, M, M/L
Bontrager Comp, alloy, 31.8mm, 5mm rise, 720mm width
Size: L, XL
Bontrager Rhythm Comp, alloy, 31.8mm, 15mm rise, 750mm width |
|
Grips
| Bontrager XR Trail Comp, nylon lock-on |
|
Belongs to MY Catalog
| 2022 |
