Wheel Size
| 26" & 27.5" & 29" |
|
Bike Type
| Cross Country MTB |
|
Brake Type
| Disc |
|
Telescopic Dropper
| No |
|
Material
| Aluminium |
|
Electric
| no |
|
Frame
| Alpha Silver Aluminum, internal routing, chainstay disc brake mount, rack and kickstand mount, 135x5mm QR
Max tire size: 29x2.20" (XS & S: 27.5x2.4") |
|
Frame Material
| Aluminium |
Size  If you are on a listing page, in this field you will find all the available sizes for that specific product. If you are instead on an ad page, this field reports the Size of the spedific product that is for sale. The Size is one of the most important information for choosing the best fitting product to your body. Wehtere it is a bicycle or gear. Speaking about bike clothing and shoes, sizes follow the international size charts, but when it comes to bicycles and frames it is not possible to define a standard. Bicycles and frames come in many different shapes and geometries and this results in several sizing methods. As a general rule, though, you can assume that road bicycles are sized by the lenght the seat tube in centimeters (52, 54, 56, ...) and mountain bikes are instead sized by the S,M,L, ... rule. Our advice, is to look carefully at the sizing chart you can find in our product pages, but to be sure you are choosing the best fit for you, always refer to your trusted dealer or shop, because he is the one who is the one who can assist you at best for this purpose. | 2XS,XS,S,M,M/L,L,XL,2XL |
|
Front Suspension
| Size: XXS , XS
RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 42mm offset for 27.5'' wheel, 100mm QR, 80mm travel
Size: S
RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 42mm offset for 27.5'' wheel, 100mm QR, 100mm travel
Size: M , ML , L , XL
RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 46mm offset for 29'' wheel, 100mm QR, 100mm travel |
|
Front Suspension Travel
| 100 |
|
Suspension Layout
| Front Suspended |
|
Headset
| Semi-integrated, 1-1/8'' |
|
Front Hub
| Formula DC-20 LW, alloy, 6-bolt, 5x100mm QR |
|
Rear Hub
| Formula DC-22LW, 6-bolt, Shimano 8/9/10 freehub, 135x5mm QR |
|
Hub Spacing
| Front: 100mm;
Rear: 135mm |
|
Rims
| Size: XXS , XS , S , M , ML , L , XL
Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23mm width, presta valve
Size: M , ML , L , XL
Bontrager Kovee, double-wall, Tubeless Ready, 32-hole, 23mm width, presta valve |
|
Spokes
| NA |
|
Inflation Type
| Tubeless |
|
Tyres
| Size: XXS
Maxxis Ardent, tubeless, EXO casing, folding bead, 60tpi, 26x2.40''
Size: XS , S
Maxxis Ardent Race, tubeless, EXO casing, folding bead, 60tpi, 27.5x2.35''
Size: M , ML , L , XL
Maxxis Ardent Race, tubeless, EXO casing, folding bead, 60tpi, 29x2.35''
Size: M , ML , L , XL
Maxxis Ardent Race, tubeless, EXO casing, folding bead, 60tpi, 29x2.20'' |
|
Brakeset
| Shimano MT200 hydraulic disc
*Brake rotor Size: XXS , XS , S , M , ML , L , XL
Shimano RT26, 6-bolt,160mm
Size: L , XL
Shimano RT26, 6-bolt,180mm |
|
Shifters
| SRAM SX Eagle, 12 speed |
|
Rear Derailleur
| SRAM SX Eagle |
|
Crankset
| Size: XXS
SRAM SX Eagle, 30T steel ring, 49mm chainline, 155mm length
Size: XS , S , M
SRAM SX Eagle, 30T steel ring, 49mm chainline, 170mm length
Size: ML , L , XL
SRAM SX Eagle, 30T steel ring, 49mm chainline, 175mm length
Max chainring size 1x/2x: 34T, 3x: 42T |
|
Bottom Bracket
| Truvativ Powerspline, 73mm, threaded cartridge, 118mm spindle |
|
Cassette
| SRAM PG-1210 Eagle, 11-50, 12 speed |
|
Chain
| SRAM SX Eagle, 12 speed |
|
Pedals
| VP-536 nylon platform |
|
Power Meter
| No |
|
Saddle
| Bontrager Arvada, steel rails, 138mm width |
|
Seatpost
| Size: XXS
Bontrager alloy, 31.6mm, 12mm offset, 300mm length
Size: XS , S , M
Bontrager alloy, 31.6mm, 12mm offset, 330mm length
Size: ML , L , XL
Bontrager alloy, 31.6mm, 12mm offset, 400mm length |
|
Stem
| Size: XXS
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 35mm length
Size: XXS , XS
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 50mm length
Size: S
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 60mm length
Size: M
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 70mm length
Size: ML , L
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 80mm length
Size: XL
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 90mm length |
|
Handlebar
| Size: XXS , XS
Bontrager alloy, 31.8mm, 5mm rise, 690mm width
Size: S , M , ML , L , XL
Bontrager alloy, 31.8mm, 5mm rise, 720mm width |
|
Grips
| Bontrager XR Trail Comp, nylon lock-on |
|
Belongs to MY Catalog
| 2022 |
