Wheel Size
| 27.5" & 29" |
|
Bike Type
| Cross Country MTB |
|
Brake Type
| Disc |
|
Telescopic Dropper
| No |
|
Material
| Aluminium |
|
Electric
| no |
|
Frame
| Alpha Silver Aluminum, internal routing, chainstay disc brake mount, rack and kickstand mount, 135x5mm QR
Max tire size: 29x2.20" (XS & S: 27.5x2.4") |
|
Frame Material
| Aluminium |
Size  If you are on a listing page, in this field you will find all the available sizes for that specific product. If you are instead on an ad page, this field reports the Size of the spedific product that is for sale. The Size is one of the most important information for choosing the best fitting product to your body. Wehtere it is a bicycle or gear. Speaking about bike clothing and shoes, sizes follow the international size charts, but when it comes to bicycles and frames it is not possible to define a standard. Bicycles and frames come in many different shapes and geometries and this results in several sizing methods. As a general rule, though, you can assume that road bicycles are sized by the lenght the seat tube in centimeters (52, 54, 56, ...) and mountain bikes are instead sized by the S,M,L, ... rule. Our advice, is to look carefully at the sizing chart you can find in our product pages, but to be sure you are choosing the best fit for you, always refer to your trusted dealer or shop, because he is the one who is the one who can assist you at best for this purpose. | XS,S,M,M/L,L,XL,2XL |
|
Front Suspension
| Size: XS
RockShox Judy, coil spring, preload, TurnKey lockout, 42mm offset for 27.5'' wheel, 100mm QR, 80mm travel
Size: S
RockShox Judy, coil spring, preload, TurnKey lockout, 42mm offset for 27.5'' wheel, 100mm QR, 100mm travel
Size: M , ML , L , XL , XXL
RockShox Judy, coil spring, preload, TurnKey lockout, 46mm offset for 29'' wheel, 100mm QR, 100mm travel |
|
Front Suspension Travel
| 100 |
|
Suspension Layout
| Front Suspended |
|
Headset
| Semi-integrated, 1-1/8'' |
|
Front Hub
| Formula DC-20, alloy, 6-bolt, 5x100mm QR |
|
Rear Hub
| Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm QR |
|
Hub Spacing
| Front: 100mm;
Rear: 135mm |
|
Rims
| Bontrager Connection, double-wall, 32-hole, 20mm width, presta valve |
|
Spokes
| 14g stainless steel |
|
Inflation Type
| Inner Tube |
|
Tyres
| Size: XS , S
Bontrager XR2 Comp, wire bead, 30 tpi, 27.5x2.20''
Size: M , ML , L , XL , XXL
Bontrager XR2 Comp, wire bead, 30 tpi, 29x2.20'' |
|
Brakeset
| Shimano MT200 hydraulic disc
*Brake rotor Size: XS , S , M , ML , L , XL , XXL
Shimano RT26, 6-bolt,160mm
Size: L , XL , XXL
Shimano RT26, 6-bolt,180mm |
|
Shifters
| Shimano Deore M4100, 10 speed |
|
Rear Derailleur
| Shimano Deore M5120, long cage |
|
Crankset
| Size: XS , S , M
FSA Alpha Drive, 28T steel ring, Boost, 170mm length
Size: ML , L , XL , XXL
FSA Alpha Drive, 28T steel ring, Boost, 175mm length
Max chainring size 1x/2x: 34T, 3x: 42T |
|
Bottom Bracket
| FSA, 73mm, threaded cartridge, 122.5mm spindle |
|
Cassette
| Shimano Deore M4100, 11-46, 10 speed |
|
Chain
| KMC X10, 10 speed |
|
Pedals
| VP-536 nylon platform |
|
Power Meter
| No |
|
Saddle
| Bontrager Arvada, steel rails, 138mm width |
|
Seatpost
| Size: XS , S , M
Bontrager alloy, 31.6mm, 12mm offset, 330mm length
Size: ML , L , XL , XXL
Bontrager alloy, 31.6mm, 12mm offset, 400mm length |
|
Stem
| Size: XS
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 50mm length
Size: S
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 60mm length
Size: M
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 70mm length
Size: ML , L
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 80mm length
Size: XL , XXL
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 90mm length |
|
Handlebar
| Size: XS
Bontrager alloy, 31.8mm, 5mm rise, 690mm width
Size: S , M , ML , L , XL , XXL
Bontrager alloy, 31.8mm, 5mm rise, 720mm width |
|
Grips
| Bontrager XR Trail Comp, nylon lock-on |
|
Belongs to MY Catalog
| 2022 |
