Wheel Size
| 26" & 27.5" & 29" |
|
Bike Type
| Cross Country MTB |
|
Brake Type
| Disc |
|
Telescopic Dropper
| No |
|
Material
| Aluminium |
|
Electric
| no |
|
Frame
| Alpha Silver Aluminum, internal routing, chainstay disc brake mount, rack and kickstand mount, 135x5mm QR
Max tire size: 29x2.20" (XS & S: 27.5x2.4") |
|
Frame Material
| Aluminium |
Size  If you are on a listing page, in this field you will find all the available sizes for that specific product. If you are instead on an ad page, this field reports the Size of the spedific product that is for sale. The Size is one of the most important information for choosing the best fitting product to your body. Wehtere it is a bicycle or gear. Speaking about bike clothing and shoes, sizes follow the international size charts, but when it comes to bicycles and frames it is not possible to define a standard. Bicycles and frames come in many different shapes and geometries and this results in several sizing methods. As a general rule, though, you can assume that road bicycles are sized by the lenght the seat tube in centimeters (52, 54, 56, ...) and mountain bikes are instead sized by the S,M,L, ... rule. Our advice, is to look carefully at the sizing chart you can find in our product pages, but to be sure you are choosing the best fit for you, always refer to your trusted dealer or shop, because he is the one who is the one who can assist you at best for this purpose. | 2XS,XS,S,M,M/L,L,XL,2XL |
|
Front Suspension
| Size: XXS
SR Suntour XCM 30, coil spring, lockout, preload, 100mm QR, 100mm travel, 26'' wheel
Size: XS
SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42mm offset for 27.5'' wheel, 100mm QR, 80mm travel
Size: S
SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42mm offset for 27.5'' wheel, 100mm QR, 100mm travel
Size: M , ML , L , XL , XXL
SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 46mm offset for 29'' wheel, 100mm QR, 100mm travel |
|
Front Suspension Travel
| 100 |
|
Suspension Layout
| Front Suspended |
|
Headset
| Semi-integrated, 1-1/8'' |
|
Front Hub
| Formula DC-20, alloy, 6-bolt, 5x100mm QR |
|
Rear Hub
| Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm QR |
|
Hub Spacing
| Front: 100mm;
Rear: 135mm |
|
Rims
| Size: XXS
Bontrager Connection, alloy, double-wall, 32-hole, 20mm width, schrader valve
Size: XS , S , M , ML , L , XL , XXL
Bontrager Connection, double-wall, 32-hole, 20mm width, schrader valve |
|
Spokes
| 14g stainless steel |
|
Inflation Type
| Inner Tube |
|
Tyres
| Size: XXS
Bontrager XR2 Comp, wire bead, 30 tpi, 26x2.20''
Size: XS , S
Bontrager XR2 Comp, wire bead, 30 tpi, 27.5x2.20''
Size: M , ML , L , XL , XXL
Bontrager XR2 Comp, wire bead, 30 tpi, 29x2.20'' |
|
Brakeset
| Tektro HD-M275 hydraulic disc |
|
Shifters
| Shimano Altus M315, 8 speed |
|
Front Derailleur
| Shimano Altus M315, 34.9mm clamp, top swing, dual pull |
|
Rear Derailleur
| Shimano Altus M310 |
|
Crankset
| Size: XXS
Prowheel TM-CY10, 36/22, 160mm length
Size: XS , S , M
Shimano M315, 36/22, 170mm length
Size: ML , L , XL , XXL
Shimano M315, 36/22, 175mm length
Max chainring size 1x/2x: 34T, 3x: 42T |
|
Bottom Bracket
| VP BC73, 73mm, threaded cartridge |
|
Cassette
| Shimano HG200, 12-32, 8 speed |
|
Chain
| KMC Z8.3, 8 speed |
|
Pedals
| VP-536 nylon platform |
|
Power Meter
| No |
|
Saddle
| Bontrager Arvada, steel rails, 138mm width |
|
Seatpost
| Size: XXS
Bontrager alloy, 31.6mm, 12mm offset, 300mm length
Size: XS , S , M
Bontrager alloy, 31.6mm, 12mm offset, 330mm length
Size: ML , L , XL , XXL
Bontrager alloy, 31.6mm, 12mm offset, 400mm length |
|
Stem
| Size: XXS
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 35mm length
Size: XS
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 50mm length
Size: S
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 60mm length
Size: M
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 70mm length
Size: ML , L
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 80mm length
Size: XL , XXL
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 90mm length |
|
Handlebar
| Size: XXS , XS
Bontrager alloy, 31.8mm, 5mm rise, 690mm width
Size: S , M , ML , L , XL , XXL
Bontrager alloy, 31.8mm, 5mm rise, 720mm width |
|
Grips
| Bontrager XR Endurance Comp, lock-on |
|
Belongs to MY Catalog
| 2022 |
