Wheel Size
| 27.5" & 29" |
|
Bike Type
| Cross Country MTB |
|
Brake Type
| Disc |
|
Telescopic Dropper
| No |
|
Material
| Aluminium |
|
Electric
| no |
|
Frame
| Alpha Silver Aluminum, internal routing, chainstay disc brake mount, rack and kickstand mount, 135x5mm QR
Max tire size: 29x2.20" (XS & S: 27.5x2.4") |
|
Frame Material
| Aluminium |
Size  If you are on a listing page, in this field you will find all the available sizes for that specific product. If you are instead on an ad page, this field reports the Size of the spedific product that is for sale. The Size is one of the most important information for choosing the best fitting product to your body. Wehtere it is a bicycle or gear. Speaking about bike clothing and shoes, sizes follow the international size charts, but when it comes to bicycles and frames it is not possible to define a standard. Bicycles and frames come in many different shapes and geometries and this results in several sizing methods. As a general rule, though, you can assume that road bicycles are sized by the lenght the seat tube in centimeters (52, 54, 56, ...) and mountain bikes are instead sized by the S,M,L, ... rule. Our advice, is to look carefully at the sizing chart you can find in our product pages, but to be sure you are choosing the best fit for you, always refer to your trusted dealer or shop, because he is the one who is the one who can assist you at best for this purpose. | XS,S,M,M/L,L,XL,2XL |
|
Front Suspension
| Size: XS
SR Suntour XCE 28, coil spring, preload, 42mm offset for 27.5'' wheel, 100mm QR, 80mm travel
Size: S
SR Suntour XCE 28, coil spring, preload, 42mm offset for 27.5'' wheel, 100mm QR, 100mm travel
Size: M , ML , L , XL , XXL
SR Suntour XCE 28, coil spring, preload, 46mm offset for 29'' wheel, 100mm QR, 100mm travel |
|
Front Suspension Travel
| 100 |
|
Suspension Layout
| Front Suspended |
|
Headset
| Semi-integrated, 1-1/8'' |
|
Front Hub
| Formula DC-20, alloy, 6-bolt, 5x100mm QR |
|
Rear Hub
| Formula DC-31, alloy, 6-bolt, 6/7/8 speed freewheel, 135x5mm QR |
|
Hub Spacing
| Front: 100mm;
Rear: 135mm |
|
Rims
| Bontrager Connection, double-wall, 32-hole, 20mm width, schrader valve |
|
Spokes
| 14g stainless steel |
|
Inflation Type
| Inner Tube |
|
Tyres
| Size: XS , S
Bontrager XR2 Comp, wire bead, 30 tpi, 27.5x2.20''
Size: M , ML , L , XL , XXL
Bontrager XR2 Comp, wire bead, 30 tpi, 29x2.20''
Size: M , ML , L , XL , XXL
Bontrager XR2 Comp, wire bead, 30 tpi, 29x2.00'' |
|
Brakeset
| Size: XS , S , M , ML , L , XL , XXL
Tektro MD-M280 mechanical disc, 160mm rotor
Size: XS , S , M , ML , L , XL , XXL
Tektro MD-M281 mechanical disc, 160mm rotor |
|
Shifters
| Shimano Altus EF500, 7 speed |
|
Front Derailleur
| Shimano Tourney TY300, 34.9mm clamp, down swing, down pull |
|
Rear Derailleur
| Shimano Tourney TY300, long cage, 34T max cog |
|
Crankset
| Size: XS , S , M
Shimano Tourney TY301, 42/34/24, 170mm length
Size: ML , L , XL , XXL
Shimano Tourney TY301, 42/34/24, 175mm length
Max chainring size 1x/2x: 34T, 3x: 42T |
|
Bottom Bracket
| VP BC73, 73mm, threaded cartridge |
|
Cassette
| Shimano TZ500, 14-28, 7 speed |
|
Chain
| KMC Z7, 7 speed |
|
Pedals
| VP-536 nylon platform |
|
Power Meter
| No |
|
Saddle
| Bontrager Arvada, steel rails, 138mm width |
|
Seatpost
| Size: XS , S
Bontrager alloy, 31.6mm, 12mm offset, 330mm length
Size: M
Bontrager alloy, 31.6mm, 12mm offset, 360mm length
Size: ML , L , XL , XXL
Bontrager alloy, 31.6mm, 12mm offset, 400mm length |
|
Stem
| Size: XS
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 50mm length
Size: S
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 60mm length
Size: M
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 70mm length
Size: ML , L
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 80mm length
Size: XL , XXL
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 90mm length |
|
Handlebar
| Size: XS , S
Bontrager alloy, 31.8mm, 5mm rise, 690mm width
Size: M , ML , L , XL , XXL
Bontrager alloy, 31.8mm, 5mm rise, 720mm width |
|
Grips
| Bontrager XR Endurance Comp, lock-on |
|
Belongs to MY Catalog
| 2022 |
