Wheel Size
| 27.5" & 29" |
|
Bike Type
| eMTB |
|
Brake Type
| Disc |
|
Telescopic Dropper
| No |
|
Material
| Aluminium |
|
Electric
| yes |
|
Frame
| Alpha Platinum Aluminium, Removable Integrated Battery (RIB), tapered head tube, internal derailleur and dropper post routing, G2 Geometry on 29ers, Boost148 |
|
Frame Material
| Aluminium |
Size  If you are on a listing page, in this field you will find all the available sizes for that specific product. If you are instead on an ad page, this field reports the Size of the spedific product that is for sale. The Size is one of the most important information for choosing the best fitting product to your body. Wehtere it is a bicycle or gear. Speaking about bike clothing and shoes, sizes follow the international size charts, but when it comes to bicycles and frames it is not possible to define a standard. Bicycles and frames come in many different shapes and geometries and this results in several sizing methods. As a general rule, though, you can assume that road bicycles are sized by the lenght the seat tube in centimeters (52, 54, 56, ...) and mountain bikes are instead sized by the S,M,L, ... rule. Our advice, is to look carefully at the sizing chart you can find in our product pages, but to be sure you are choosing the best fit for you, always refer to your trusted dealer or shop, because he is the one who is the one who can assist you at best for this purpose. | S (27.5") |
|
Size Notes
| S (27.5" wheel) |
|
Front Suspension
| RockShox Judy Silver TK, Solo Air, rebound adjust, TurnKey hydraulic lockout, tapered steerer, G2 Geometry w/51mm offset, Boost110, 100mm travel |
|
Front Suspension Travel
| 100 |
|
Suspension Layout
| Front Suspended |
|
Headset
| NA |
|
Front Hub
| Bontrager Boost110 |
|
Rear Hub
| Bontrager sealed bearing alloy axle, Boost148 |
|
Hub Spacing
| Front: 110mm Boost;
Rear: 148mm Boost |
|
Rims
| Bontrager Kovee 23, Tubeless Ready, 32-hole double-walled, tubeless strips and valves sold separately |
|
Spokes
| NA |
|
Tyres
| Bontrager XR3, 29x2.40Ë (15.5: 27.5x2.35Ë) |
|
Brakeset
| Shimano MT200 hydraulic disc |
|
Shifters
| Shimano Deore M6000, 10 speed |
|
Rear Derailleur
| Shimano Deore M6000, Shadow Plus |
|
Crankset
| FSA 310, 15T w/chain guard |
|
Bottom Bracket
| FSA 310, 15T w/chain guard |
|
Cassette
| Shimano HG50, 11-42, 10-speed |
|
Chain
| KMC X10 |
|
Power Meter
| No |
|
Saddle
| Bontrager Arvada |
|
Seatpost
| Bontrager alloy, 2-bolt head, 31.6 mm, 12 mm offset |
|
Stem
| Bontrager alloy, 31.8 mm, 7-degree, Blendr compatible |
|
Handlebar
| Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width |
|
Grips
| Bontrager XR Endurance Elite |
|
Motor Brand
| Bosch |
|
Motor Model
| Performance Line CX - Derailleur (MY 20) |
|
Battery Brand
| Bosch |
|
Battery Model
| PowerPack 500 |
|
Belongs to MY Catalog
| 2019 |
