Frame
|
OCLV Mountain Carbon, internal storage, tapered head tube, Knock Block 2.0, internal guided routing, downtube guard, magnesium rocker link, Mino Link, ABP, Boost148, 120mm travel
Max tire size: 29x2.5" |
Headset
|
Knock Block 2.0 Integrated, 72-degree radius (includes infinite-radius chip), sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom |
Shock
|
Fox Performance Float DPS, 3-position damper, 185mm x 50mm |
Rear Suspension Travel
|
120 |
Front Suspension
|
Fox Rhythm 34, Float EVOL air spring, GRIP damper, tapered steerer, 44mm offset, Boost110, 15mm Kabolt axle, 120mm travel |
Front Suspension Travel
|
130 |
Hub Spacing
|
Front: 110mm Boost;
Rear: 148mm Boost |
Rims
|
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle
w/rearstrip: Bontrager TLR |
Spokes
|
NA |
Front Wheel
|
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle |
Rear Wheel
|
Size: XS
Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 54, 6-bolt, Boost148, 12mm thru axle
Size: S, M, M/L, L, XL
Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Boost148, 12mm thru axle
Skewer rear: Bontrager Switch thru axle, removable lever |
Tubes
|
Bontrager TLR sealant, 6oz |
Tyres
|
Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120tpi, 29.x2.40'' |
Brakeset
|
Shimano 4-piston hydraulic disc, M6100 lever, M6120 caliper
*Brake rotor Size: XS, S, M, M/L, L, XL
Shimano RT66, 6-bolt, 160mm
Size: XS, S, M, M/L, L, XL
Shimano RT66, 6-bolt, 180mm |
Rear Derailleur
|
Shimano XT M8100, long cage |
Crankset
|
Size: XS, S, M, M/L, L
Shimano Deore M6120, 30T ring, 55mm chainline, 170mm length
Size: XL
Shimano Deore M6120, 30T ring, 55mm chainline, 175mm length
Max chainring size Max: 36T (oval - 34T) Min: 28T |
Bottom Bracket
|
Shimano SM-BB52, 73mm, threaded external bearing |
Cassette
|
Shimano SLX M7100, 10-51, 12 speed |
Chain
|
Shimano SLX M7100, 12 speed |
Pedals
|
Not included |
Saddle
|
Bontrager Arvada, steel rails, 138mm width |
Seat Post
|
Size: XS, S
TranzX JD-YSP39, 100mm travel, internal routing, 34.9mm
Size: M, M/L
TranzX JD-YSP39, 150mm travel, internal routing, 34.9mm
Size: L, XL
TranzX JD-YSP39, 170mm travel, internal routing, 34.9mm |
Stem
|
Bontrager Elite, 35mm, 0 degree, 45mm length |
Handlebar
|
Size: XS, S
Bontrager Line, alloy, 35mm, 27.5mm rise, 750mm width
Size: M, M/L, L, XL
Bontrager Line, alloy, 35mm, 27.5mm rise, 780mm width |
Grips
|
Bontrager XR Trail Comp, nylon lock-on |
